Instrumentation
RF/Microwave capacitor, combined with thin-film and thick-film circuit technologies, empower precision instruments in filtering and resonance. By delivering high Q-factors, they ensure high-precision signal sampling and low-noise stability
Application Overview
Primarily utilized in RF front-end filtering and bypassing for spectrum analyzers and oscilloscopes, while thin-film and thick-film circuits, leveraging their high degree of integration, are extensively applied in RC matching networks within precision probes. From the dual dimensions of component performance and system-level integration, both technologies collaboratively guarantee high-fidelity signal acquisition and transmission stability.
Application Features
Featuring ultra-high Q and minimal ESR, DLC RF/Microwave MLCCs effectively reduce system noise floor and control thermal buildup. When integrated with high-precision thin-film and thick-film circuits, they enable precise RC matching and low parasitic inductance. These RF capacitors perform critical functions in signal coupling, filtering, impedance matching, and power transmission—perfectly suited for precision instruments like Mass Spectrometry and ICP. By ensuring pure and efficient signaling, they enhance linearity and zero-point stability during high-speed sampling, meeting the most stringent measurement resolution requirements.
-
Ultra-low ESR -
Ultra-high Q -
High-precision thin-film/thick-film circuits -
Low parasitic inductance -
Impedance matching
Recommended Products
-
DLC 70 Series
Porcelain Capacitor -
DLC 70 Series
For High RF Power -
Broadband Multilayer Ceramic Capacitor
-
Single Layer Ceramic Capacitor
-
Silicon Capacitor
-
Bridge Thermal Conductor
